General Information & Highlights
With its impressive modern outern design, 320 cm print width, print speed up to 210 m2/h, 2880 dpi resolution and 14 Pl. droplet size, makes it possible to print on with photograph-quality on many similar types of fabrics like; Bed Covers, Curtains, Wall Coverings, Seat Covers, Flags, Table Clothes, T-Shirts, Clothings…
Textile Printer, with is impressive modern outern design, print width of 320 cm, print speed up to 210 m2/h, 2880 dpi resolution and 14 pl droplet volume, makes it possible to produce much faster and with more quality.
Specifications
Color Scale | CMYK + Lc + Lm – CMYK |
Drop Volume | 13 Pl. – 3,5 Pl. |
Drying System | Halogen Heather – Fan |
Ink Types | Sublimation / Reactive / Pigment |
Machine Size | 3000 mm x 5800 mm x 1530 mm |
Machine Size Fixation Unit | 1100 mm x 5200 mm x 2000 mm |
Machine Weight | 2900 kg. |
Power Requirements | 230v (+/-) 10% / 32A / 50HZ |
Print Heads | KM 1024i – Kyocera |
Print Resolution | 2880 DPI |
Print Speed Up to | 210 m2 / h – 200 m2 / h |
Print Width | 3200 mm |
Printhead Quantity | 12 (Max.) – 4 (Max.) |
RIP Software | PhotoPrint – Ergosoft (Opt.) |
Standart | Fixation Unit 3200 mm |
Print Media
- Curtain
- Fabric
- Raschel fabric
- Satin fabric
- Seat Fabric
