General Information & Highlights
High quality prints on PVC, Vinyl, Blacklit Film, Photo Paper, Flex, Textile ( Roller blind…etc) with 2880 dpi resolution…
Specifications
Color Scale | CMYK + Lc + Lm + W |
Drop Volume | 6 Pl. – 13 Pl – 7 Pl – 3 Pl |
Drying System | UV Curing – LED Curing |
Ink Types | UV – LED |
Machine Size | 3200 mm x 5000 mm x 1850 mm |
Machine Weight | 2400 kg. |
Power Requirements | 230v (+/-) 10% / 40A / 50HZ/ 60HZ/ |
Print Heads | KM 1024i – Ricoh Gen5 – Kyocera |
Print Resolution | 2880 DPI – 1200 DPI – 2400 DPI |
Print Speed Up to | 90 m2 / h |
Print Width | 2050 mm |
Printhead Quantity | 16 (Max.) – 8 (Max.) – 6 (Max.) |
RIP Software | PhotoPrint – Caldera (Opt.) |
Print Media
- Advertising Media
- Banner
- Canvas
- Curtain
- Fabric
- Leather
- One Vay Vision
- Vinylex
